Ai performance
|
Support the privatization deployment of ultra-large-scale parametric models under the Transformer architecture, such as the Gemma, ChatGLM, Qwen, Phi, and other large language models. It supports traditional network architectures such as CNN, RNN, and LSTM, and supports the import and export of RKNN models; Support a variety of deep learning frameworks, including TensorFlow, TensorFlow Lite, PyTorch, Caffe, ONNX, and Darknet. It also supports the development of custom operators. Support Docker container management technology. It supports the real-time object detection algorithm YOLO (You Only Look Once), which is faster and more real-time compared with traditional object detection methods, and can accurately identify and locate multiple target objects in images or videos, powering AI applications. |
|
Soc
|
|
|
Cpu
|
Octa-core 64-bit processor (4×A72 + 4×A53), up to 2.2GHz |
|
Gpu
|
G52 MC3 @ 1GHz, supports OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1, embedded high-performance 2D acceleration hardware |
|
Npu
|
6 TOPS computing power NPU, support INT4/INT8/INT16/FP16/BF16/TF32 operation, support dual-core collaborative or independent work, support multi-task, multi-scenario parallelism. |
|
Vpu
|
Decode: 8K@30fps/4K@120fps (H.265/HEVC, VP9, AVS2, AV1), 4K@60fps (H.264/AVC) Encode: 4K@60fps (H.265/HEVC, H.264/AVC) |
|
Ram
|
LPDDR5 (4GB/8GB/16GB Optional) |
|
Storage
|
eMMC (16GB/32GB/64GB/128GB/256GB Optional) |
|
Power
|
DC 12V (5.5mm × 2.1mm, support 12V~24V wide voltage input), 1 × DC_IN (4Pin-2.54mm) |
|
Power consumption
|
Max: 8.4W(12V/700mA), Normal: 1.2W(12V/100mA), Min: 0.24W(12V/20mA) |
|
Video input
|
2 × MIPI-CSI DPHY (1×4Lanes or 2×2Lanes, 30Pin-0.5mm) 1 × MIPI-CSI D/CPHY (DPHY(1×4 Lanes/2×2 Lanes) or CPHY(3Lanes), 30Pin-0.5mm) |
|
Audio
|
1 × MIC (2Pin-2mm), 1 × SPK (4Pin-2mm, 2×10W/6Ω or 2×10W/8Ω), 1 × 3.5mm Audio jack (Support MIC recording, American Standard CTIA) |
|
Os
|
It supports the RTLinux kernel and has excellent real-time performance, which is widely used in industrial application scenarios.
Support Android14, Linux OS, Buildroot, and domestic operating systems, providing a safe and stable system environment for product research and production. It has new industrial features such as a real-time network, Flexbus, hardware resource isolation, and DSMC to meet the needs of different industrial applications. |
|
Dimension
|
126.0 mm × 94.4mm × 14.2mm |
|
Weight
|
|
|
Environment
|
- Operating Temperature: -20℃ ~ 60℃
- Storage Temperature: -20℃ ~ 70℃
- Storage Humidity: 10%～90%RH (non-condensing)
|
|
Other interface
|
1 × RS232 (3Pin-2mm), 1 × RS485 (3Pin-2mm), 1 × CAN (3Pin-2mm), 1 × I2C (4Pin-2mm), 4 × ADC (6Pin-2mm), 1 × Debug (3Pin-2mm), 1 × LCD_PWR (6Pin-2mm), 1 × TP_I2C (6Pin-2mm), 1 × FAN (4Pin-1.25mm), 1 × Screen voltage jumper (Single-row pin headers, 6Pin-2mm) |
|
Button
|
1 × Reset, 1 × Recovery, 1 × BOOT |
