CT36B AI Smart Camera
Regular price
$49.00 USD
Regular price
Sale price
$49.00 USD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
Regular price
$49.00 USD
Regular price
Sale price
$49.00 USD
The CT36L AI smart camera is equipped with the RV1106G2 chip, which adopts the ARM Cortex-A7 architecture, has a main frequency of 1.2GHz, and is equipped with a 0.5T NPU. It is equipped with a 5-megapixel image signal processor (ISP) and supports advanced image enhancement and correction algorithms, including HDR and WDR, as well as multi-level noise reduction. The CT36L is equipped with a 3-megapixel HD lens and provides 100M Ethernet and POE power supply.
Feature
- Vision Processor RV1106G2: RV1106G2 is based on ARM Cortex-A7 32-bit CPU, integrates Neon and FPU, has a main frequency of 1.2GHz, and has the characteristics of high performance and low power consumption.
- High-performance 5-megapixel ISP: Supports advanced image enhancement and correction algorithms, including HDR and WDR, as well as multi-level noise reduction. Ensures clear images and full-color night vision effects in any lighting conditions.
- A Built-in NPU With 0.5 TOPS: Provides INT4/INT8/INT16 mixed operations and framework switching for TensorFlow/MXNet/PyTorch/Caffe/Onnx NN.
- 3-megapixel HD Camera: The camera features high sensitivity, high signal-to-noise ratio and low-light capabilities to deliver high-definition image quality and accurately capture highlight and shadow details in dynamic scenes.
- Support 100M Ethernet And POE: The adaptive 100M Ethernet port and POE ensure power supply and video signal transmission through a single Ethernet cable, plug and play, and the setup is efficient and convenient.
Camera Parameters
| Image Sensor | SC3336 |
| CMOS Size | 1/2.8" |
| Pixel | 3-megapixel (2304×1296) |
| Aperture | F2.0 |
| Field of View | 98.3° |
| Focal Length | 3.95mm |
| Distortion | < 33% |
| Maximum Frame Rate | 2304*1296@30fps |
| Focus Mode | Manual Focus |
| Camera Type | Color |
| Cpu | |
|---|---|
| Npu | |
| Vpu | |
| Ram | |
| Storage | |
| Power | |
| Os | |
| Dimension | |
| Environment |
| Product tutorials | Click Here |
|---|---|
| Product datasheet | Click Here |
| Sdk software and firmware files | Click Here |
