The AIBOX-8550 is equipped with a Qualcomm QCS8550 octa-core AI processor, integrating a 48 TOPS NPU, supporting mainstream AI large language models and deep learning frameworks. It features a built-in Adreno 740 GPU, supporting ray tracing and 8K video codecs. Utilizing an industrial-grade all-metal casing, it offers efficient heat dissipation, ensuring stable operation around the clock and meeting the demands of demanding industrial applications.

Feature

  • High-Performance Processor Qualcomm QCS8550: The QCS8550 features an eight-core Kryo CPU based on the ARM architecture, with a clock speed of up to 3.36 GHz, providing powerful support for high-performance computing and multitasking.
  • Deployment of Large AI Models: Supports the private deployment of large-scale Transformer models (including Qwen, Llama, Gemma, DeepSeek-R1, and Phi series), as well as mainstream deep learning frameworks such as TensorFlow, PyTorch, Caffe, and ONNX.
  • Supports Ray Tracing Technology: Features an Adreno 740 GPU, providing full ray tracing support and compatibility with OpenGL ES 3.2, Vulkan 1.2, and OpenCL 3.0. Combined with Adreno Neural Processing technology, it significantly enhances graphics and AI computing performance.
  • 8K Video Encoding and Decoding: Advanced video processing supporting 8K@60fps/4K@240fps decoding and 8K@30fps/4K@120fps encoding.

Product Overview

Soc

Qualcomm QCS8550

Cpu

Qualcomm Kryo® CPU: Octa-core 64-bit (1×GoldPlus@3.2GHz + (2+2)Gold@2.8GHz + 3×Silver@2.0GHz), 4nm advanced process, maximum frequency up to 3.36GHz

Gpu

Adreno 740 GPU: Supports ray tracing technology, OpenGL ES 3.2, Vulkan 1.2, full-profile OpenCL 3.0, and Adreno NN Direct

Npu

Dual eNPU V3: Equipped with 4 HVX (Hexagon Vector Extensions), 1 HMX (Hexagon Matrix Extension); Computing power up to 48 TOPS (INT8), 12 TOPS (FP16)

Ram

16GB LPDDR5x

Storage

256GB UFS4.0

Power

DC 12V/5A (5.5 × 2.1mm)

Power consumption

Normal: 4.32W(12V/360mA), Max: 20W(12V/1670mA), Min(Sleep): 0.6W(12V/50mA)

Encoding decoding

Video decoding: 8K@60fps/4K@240fps H.265/H.264/VP9/AV1
Video encoding: 8K@30fps/4K@120fps H.265/H.264
Supports concurrent 4K@60fps decoding and 4K@60fps encoding for wireless display scenarios

Os

Ububtu

Software support
  • Supports on-premises deployment of large-scale parameter models based on the Transformer architecture, such as large language models (LLMs) including the Deepseek-R1 series, Gemma series, Llama series, Qwen series, Phi series, etc.
  • Supports the QNN AI inference framework, as well as various deep learning frameworks including TensorFlow, TensorFlow Lite, PyTorch, ONNX, etc.
Dimension

93.4mm × 93.4mm × 50.0mm

Weight

≈ 500g

Environment

Operating Temperature: -20℃~60℃, Storage Temperature: -20℃~70℃, Operating Humidity: 10%~90%RH (No condensation)

Ethernet

2 × Gigabit Ethernet (1000Mbps/RJ45)

Usb

2 × USB3.0 (Max: 1A), 1 × Type-C (For download)

Button

1 × Power, 1 × Recovery
