IPC-M10R800-A3399C V2 Industrial Panel Computer

Regular price $279.00 USD
Regular price Sale price $279.00 USD
Shipping calculated at checkout.

⭐️Get 5% Off (First Order) - Code: TCHIP5

Storage: 2G RAM+32G ROM
  • American Express
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Union Pay
  • Visa
Brand: Firefly
Availability: 6 in stock
Regular price $279.00 USD
Regular price Sale price $279.00 USD

This industrial-grade tablet is built on the powerful AIO-3399C open-source platform, featuring a 10-point capacitive touchscreen and an HD display for exceptional clarity. Encased in a rugged, dust-resistant, and interference-proof housing, it ensures long-term stable operation in demanding environments.

Feature

  • Hexa-core 64-bit Powerful Processor: ARM's new Cortex-A72 architecture, six-core 64-bit high-performance processor, main frequency up to 1.8GHz. Integrated quad-core Mali-T860 GPU, supports VP9, H.264 encoding, 4K HDR, and supports up to 4K hard decoding.
  • IPS High Quality Screen: Equipped with a 10.1-inch 800 x 1280 resolution IPS high-end screen, it supports same-screen/different-screen display and full-screen HD dual-screen output with bright colors and clear details.
  • 10-point Capacitive Touch Screen: G+G capacitive touch screen, 10-point touch, high-sensitivity touch, stable operation, bring you an incredible experience.
  • High-quality Metal Enclosure: Industrial-grade metal shell, fanless design, dust-proof, shock-proof, anti-interference, wear-resistant, excellent heat dissipation performance, high temperature resistance, and long-term stable operation.

Hardware Overview

Soc

Rockchip RK3399

Cpu

Hexa-core 64-bit ARM processor, dual-core Cortex-A72 (Big core)+quad-core Cortex-A53 (Little core) frequency up to 1.8GHz

Gpu

Quad-core ARM Mali-T860

Support OpenGL ES 1.1/2.0 /3.0, OpenVG1.1, OpenCL, Directx11

Vpu
  • 4K@60fps H264/VP9 video decoding
  • 1080P multi-format video decoding (WMV, MPEG-1/2/4, VP8)

1080P H.264/VP8 video encoding

Ram

2GB/4GB dual-channel LPDDR4

Storage

8GB/16GB high-speed eMMC

1 * TF Card

Power

DC 12V-2A(5.5 × 2.1mm)

Display
  • 1*HDMI2.0 (4K@60Hz display, support HDCP 1.4/2.2)
  • 1*DP1.2 (4K@60Hz, Via USB-C)
Os

Support Android, Linux and Ubuntu

Dimension

260.2 mm*177.3 mm*30.5mm

Environment
  • Operating Temperature: -10℃- 50℃
  • Storage Temperature: -20℃- 60℃
Wireless network

2.4GHz / 5GHz dual-band WiFi, 802.11a/b/g/n/ac protocol, support Bluetooth 4.1 expanded to 3G/4G module

Usb

USB-C(OTG),1 x USB3.0,2 x USB2.0

Other
  • Screen: 10.1-inch IPS screen
  • Resolution: 800×1280 (10:16)
  • Touch screen: 10-point capacitive touch screen
  • Brightness: 300cd/m²
  • Contrast Ratio: 1000:1
  • Port: MIPI(40Pin)
Product tutorials Click Here
Sdk software and firmware files Click Here
