EC-R3588SPC Rockchip RK3588S Industrial Computer

$229.00 USD
$259.00 USD $229.00 USD
-12%
Shipping calculated at checkout.
Storage: 4G RAM+32G ROM
  • American Express
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Union Pay
  • Visa
Brand: Firefly
Availability: 50 in stock
Collections:
FireflyEC-A1684JD4 8-Core Embeded Industrial PC
EC-A1684JD4 8-Core Embeded Industrial PC
EC-A1684JD4 FD Embedded Industrial PC
FireflyEC-A1684JD4 FD Embedded Industrial PC
$229.00 USD
$259.00 USD $229.00 USD

Soc

RockChip RK3588S
Cpu

Octa-core 64-bit (4×Cortex-A76+4×Cortex-A55), 8nm lithography process, frequency up to 2.4GHz
Gpu
  • ARM Mali-G610 MP4 quad-core GPU
  • Support OpenGL ES3.2 / OpenCL 2.2 / Vulkan1.1, 450 GFLOPS
Npu
  • NPU computing power up to 6 TOPS
  • Support INT4/INT8/INT16 mixed operation, support framework switching of TensorFlow / MXNet / PyTorch / Caffe
Vpu

Video decoding:

  • 8K@60fps H.265/VP9/AVS2
  • 8K@30fps H.264 AVC/MVC
  • 4K@60fps AV1
  • 1080P@60fps MPEG-2/-1/VC-1/VP8

Video encoding:

  • 8K@30fps encoding, support H.265 / H.264
Ram

4GB/8GB/16GB 64bit LPDDR4/LPDDR4x/LPDDR5 (Up to 32GB optional)
Storage

16GB/32GB/64GB/128GB eMMC
Storage expansion
  • 1 × M.2 slot is for 2242 SATA3.0 SSD (default), compatible with 2242 PCIe2.0 NVMe SSD
  • 1 × TF Card
Power

DC12V voltage input (DC5.5×2.1mm)
Power consumption
  • Idle: ≈0.42W (12V/35mA)
  • Typical: ≈2.25W (12V/190mA)
  • Max: ≈12W (12V/1000mA)
Video output
  • 1 × HDMI2.1 (8K@60fps or 4K@120fps)
  • 1 × DP1.4 (8K@30fps)
    *Support dual screen output with different displays
Audio output
  • 1 × 3.5mm audio jack (with Mic recording)
  • 1 × HDMI2.1 audio output
  • 1 × DP1.4 audio output
Audio output
  • 1 × 3.5mm audio jack (with Mic recording)
  • 1 × HDMI2.1 audio output
  • 1 × DP1.4 audio output
Os

Android 12.0, Ubuntu Desktop and Server
Dimension

96.6mm × 72mm × 64mm
Weight

≈0.45kg
Environment
  • Operating Temperature: -20℃～60℃
  • Storage Temperature: -20℃～70℃
  • Operating humidity: 10%～90% (non-condensing)
Wireless network
  • 2.4GHz / 5GHz dual-band WiFi, 802.11 a/b/g/n/ac protocol
  • Bluetooth 4.2 (support BLE)
  • Support 4G LTE wireless network
Ethernet
  • 1 × 100Mbps Ethernet (RJ45)
  • 1 × 1000Mbps Ethernet (RJ45)
Other interface

RS232, RS485, CAN, relay and more
Usb
  • 1 × USB3.0 (current limit: 1A)
  • 1 × USB2.0（current limit: 500mA）
  • 1 × USB-C multi-function port (USB3.0 OTG / DP1.4) (current limit: 2A)
Product tutorials Click Here
Sdk software and firmware files Click Here
