The EC-A3576C is equipped with Rockchip's octa-core AIoT processor RK3576, integrating a 6-TOPPS NPU, boasting powerful computing capabilities and supporting private deployment of modern mainstream large language models. It features 4K high frame rate video decoding capabilities, utilizes an industrial-grade all-aluminum alloy casing, and employs fanless, efficient heat dissipation to ensure stable operation 24/7.

Feature

  • Rockchip RK3576: The EC-A3576C features an 8-core 64-bit RK3576 processor with a big.LITTLE architecture and a clock speed of up to 2.2GHz, providing powerful support for high-performance computing and multitasking. Equipped with a Mali-G52 MC3 GPU, it enables heterogeneous computing to meet the needs of graphics-intensive applications.
  • Private Deployment of AI Models: It supports private deployment of ultra-large-scale parametric models based on the Transformer architecture, such as large language models like Gemma, ChatGLM, Qwen, and Phi.
  • High-bandwidth LPDDR5 Memory: LPDDR5 memory offers larger capacity, higher bandwidth, faster data transfer rates, lower power consumption, and employs more advanced error correction code technology.
  • Built-in 16-megapixel ISP: It features a built-in 16-megapixel image signal processor (ISP) that supports low-light noise reduction, an RGB-IR sensor, and HDR up to 120dB. The AI-ISP further enhances image quality in low-noise environments.

Product Overview

Soc

Rockchip RK3576

Cpu

Octa-core 64-bit processor (4×A72 + 4×A53) with a maximum frequency of 2.2GHz

Gpu

G52 MC3 @ 1GHz, supports OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1, embedded high-performance 2D acceleration hardware

Npu

6 TOPS computing power NPU, support INT4/INT8/INT16/FP16/BF16/TF32 operation, support dual-core collaborative or independent work, support multi-task, multi-scenario parallelism

Ram

LPDDR5 (4GB/8GB/16GB optional)

Storage

eMMC (16GB/32GB/64GB/128GB/256GB optional)

Power

DC 12V (5.5mm × 2.1mm, support 12V~24V wide voltage input)

Power consumption

Max: 8W(12V/667mA), Normal: 3W(12V/250mA), Min: 1.7W(12V/142mA)

Audio

1 × 3.5mm Audio jack (Support MIC recording, American Standard CTIA)

Encoding decoding

Decode: 8K@30fps/4K@120fps (VP9, AVS2, AV1), 4K@60fps (H.264/AVC)
Encode: 4K@60fps (H.264/AVC)

Os

It supports the RTLinux kernel. It supports operating systems such as Android 14, Linux, and Buildroot. It features advanced industrial characteristics such as real-time networking, Flexbus, hardware resource isolation, and DSMC.

Dimension

188.00mm × 94.94mm × 50.65mm

Weight

≈760g

Environment

Operating Temperature: -20℃ ~ 60℃, Storage Temperature: -20℃ ~70℃, Storage Humidity: 10%~90%RH(non-condensing)

Usb

1 × USB3.0 (HOST, Max: 1.2A), 1 × USB2.0 (HOST, Max: 0.5A), 1 × Type-C (OTG/DP1.4)

Other

1 × SIM Card, 1 × WiFi antenna, 1 × 4G antenna
